Introduction
DAF Clarifier-water purification device is composed of high-efficiency vortex reactor and fifth-generation flotation type solid-liquid separation equipment, which can efficiently remove inorganic particulate matter, algae matter, colloidal matter and grease in water bodies such as rivers, reservoirs, lakes and seawater. And organic solid substances, etc., have a good purification effect.
Application Range
● Water plant pretreatment
● Seawater desalination pretreatment
● Black and smelly river treatment
● Purification of water bodies such as river water, lake water, and reservoir water
Technical Characteristics
● The application of high-efficiency vortex reactor greatly improves the efficiency of flocculation reaction and reduces the cost of chemical use
● The hydraulic load can be as high as 30m3/(m2·H) or more, which is more than 10 times higher than the traditional device
● High-performance dissolved gas technology, the dissolved gas efficiency is above 95%, and the dissolved gas-water reflux ratio is within 10%
● High-efficiency nano-level bubble generation technology
Significant Advantages
Low energy consumption, low cost, small area, good water output
Water purification device
The hydraulic load is as high as 30m3/m2.H or more, which is more than 10 times higher than the traditional device
Operating cost per ton of water is within 0.1 yuan/T, which is 2-3 times lower than traditional devices
Under the condition of complete transportation, the processing capacity of a single set can be as high as 20,000T/D.
